Product Details:

Place of Origin: China
Brand Name: SMART LED
Certification: CE,ROSH,FCC,EMC
Model Number: P1.86 LED 2560mm*1440mm

Payment & Shipping Terms:

Minimum Order Quantity: no requirement
Packaging Details: Wooden package
Delivery Time: 15 Days (Custom-made)
Payment Terms: T/T
Supply Ability: no requirement
Get Best Price Contact Now

Detail Information

Item: P1.86 LED Display Square Box LED Lamp: SMD 1515
Dot Density: 288906 Led Driving Method: 1/43 Scan
Cabinet Size: 2560mm*1440mm Resolution: 1376*774
Protective Grade: IP33 Refresh Rate: >3840Hz
Brightness: 650mcd Cabinet Materials: Aluminum
High Light:

P1.86 LED Touch Smart Board

,

3840hz LED Touch Smart Board

,

LED Smart Board 2560mm*1440mm

Product Description

LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz











P1.86 2560mmx1440mmIndoor SMD 1515 GOB HD LED TV Video Box IP33 Show Indoor LED Video Wall



P1.86 HD LED Display Indoor Size: 640*480mm



LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 0

Applications

P3 Indoor Display HD-LED Video screen 1920Hz Magnet Install Size:5.184m*2.304m



Product Features

* Cabinet Install to the wall,Module magnet service

* Used LED Processor can open 2 windows on the LED Display.

* Power supply and Controller service from the front side.



What we can do

* Project advise,Make the easy project design,easy for install and service

* Free on-line support

* We will send the setting file send with the goods. And also we will keep the Project file.





PH1.86mm LED SMD Indoor Display Specification and Quotation
Technicial Parameters
LED Parameters
No.  Item  Luminous Intensity  Viewing Angle(H/V)  Wavelength  Test Condition
1  Red LED (Epistar  DICE)  800-1000 140º/120º  620-630nm  25℃,20mA
2  Green LED(Epistar DICE)  1300~1500 140º/120º  520-535nm  25℃,20mA
3  Blue LED ( Epistar DICE)  250~500 140º/120º  465-475nm  25℃,20mA
Module Specifications
1 Pixel Pitch  1.86mm LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 2
2 Pixel Configuration  3-in-1, SMD 1515
3 Module Resolution  172*86
4 Module Pixles  14792
5 Module Size  320mm X 160mm
8 Hub connection  HUB75E
Cabinet Specification
1 Cabinet Size(WXHXD)  640mmLx480mmHx60mmD           LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 3
2 Cabinet Resolution  344*258 pixels
3 Module Quanity  6 pcs
4 Cabinet Pixels  88752 dots
5 Pixel Density  288906 dots/m2
6 Average Power Consumption  100W/cabinet
7 Max. Power Consumption  300W/cabinet
8 Material  Alum Die-case
9 Cabinet Weight  8 KG
10 Product process  Cabinet Fixed
Screen Parameters
1 Whole LED Display Size  2.56m x 1.44m

LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 4

LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 5

1 Whole Display Resolution  1376 x 774
1 Cabinet quantity  4pcs*3pcs =12pcs
2 Brightness  ≥800 mcd/㎡
3 Brightness(Max./Min.)  1.2:1
4 Driving Method  1/43 Scan
5 View Angle  Horizontal 140° Vertical 120°
6 Optimal Viewing Distance  5M
7 Brightness Control  Red,Green and Blue 256  Grade/Each
8 Refresh rate  >3840hz
9 Frame Frequency  60Hz
10 Input Voltage  AC220V/50Hz or AC110V/60Hz
11 Defects Rate  ≤0.00001
12 Power Consumption  Max.:650W/㎡ Average: 200W/㎡
13 Screen weight  ≤ 120 kg
14 MTBF  >10,000 hours
15 Life span  ≥100,000 hours
16 Module Display Brightness Uniformity  <2%
17 Earth Leakage Current  <3mA
18 Protective Grade  IP33
19 Temperature-operating  -25℃~45℃
20 Humidity-operating  10%~95%
21 Controlling system  HD System
22 Operating System  WINDOWS
  LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 6
           LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 7
Control system
HD-Player software HD-VP620
LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 8

                   LED Touch Smart Board P1.86 2560mm*1440mm High Refresh:3840hz 9

1)Integrated video processing, sending card function, 6 gigabit network port output, total pixels 3.9 million points;
2)5-channel high-definition digital and analog video input, up to 4K@60Hz input;
3)Multiple audio input and output;
4)Support dual pictures PIP,POP;
5)Free switching of any channel;
6)Parameter setting and saving function, scene preset saving and recall;
7)"Navigation Settings" function, convenient for quick settings;
8)The "connection setting" function no need computer control, and directly sets the
connection parameters of each cabinet through the panel buttons;
9)The device can be debugged and controlled through panel buttons, USB, Wi-Fi
(mobile APP, developing);

LED processor connection HD-VP620
