Product Details:

Place of Origin: China
Brand Name: SMART LED
Certification: CE,ROSH,FCC
Model Number: P2.5 Indoor LED Display

Payment & Shipping Terms:

Minimum Order Quantity: no requirement
Packaging Details: Wooden package,
Delivery Time: 12 Days
Payment Terms: T/T
Supply Ability: no requirement
Get Best Price Contact Now

Detail Information

Item: P2.5 SMD Indoor Full Color LED Lamp: SMD 2020
Dot Density: 160000 Led Driving Method:: 1/32 Scan
Module Size: 320mm*160mm Module Resolution: 128*64
Protective Grade: IP33 Refresh Rate: >1920Hz
Brightness: 1000mcd Project Location: Guangzhou China
High Light:

led video wall panels

,

led wall display screen

,

160000 Dots Indoor LED Video Screen

Product Description

920Hz 160000 LED Dots Indoor LED Video Screen 300W/㎡ Average Power Consumption Shenzhen Factory 0

P2.5 Indoor Display HD-LED Video screen 1920Hz Magnet Install Size:3.84m*2.08m



Applications

920Hz 160000 LED Dots Indoor LED Video Screen 300W/㎡ Average Power Consumption Shenzhen Factory 1



Product Features

* Cabinet Install to the wall,Module magnet service

* Used LED Processor can open 2 windows on the LED Display.

* Power supply and Controller service from the front side.



What we can do

* Project advise,Make the easy project design,easy for install and service

* Free on-line support

* We will send the setting file send with the goods. And also we will keep the Project file.





    920Hz 160000 LED Dots Indoor LED Video Screen 300W/㎡ Average Power Consumption Shenzhen Factory 2    920Hz 160000 LED Dots Indoor LED Video Screen 300W/㎡ Average Power Consumption Shenzhen Factory 3



   920Hz 160000 LED Dots Indoor LED Video Screen 300W/㎡ Average Power Consumption Shenzhen Factory 4PH2.5mm LED SMD Indoor Display Specification
Technicial Parameters
LED Parameters
No. Item Luminous Intensity Viewing Angle(H/V) Wavelength Test Condition
1 Red LED (Epistar DICE) 800-1000 140º/120º 620-630nm 25℃,20mA
2 Green LED(Epistar DICE) 1300~1500 140º/120º 520-535nm 25℃,20mA
3 Blue LED (Epistar DICE) 250~500 140º/120º 465-475nm 25℃,20mA
Module Specifications
1 Pixel Pitch 2.5mm  920Hz 160000 LED Dots Indoor LED Video Screen 300W/㎡ Average Power Consumption Shenzhen Factory 5
2 Pixel Configuration 3-in-1, SMD 2020
3 Module Resolution 128 X 64
4 Module Pixles  8192
5 Module Size 320mm X 160mm
6 Module power 5V7.2A 36W
Screen Parameters
1 Whole screen size 3.84m*2.08m = 7.98sqm

 920Hz 160000 LED Dots Indoor LED Video Screen 300W/㎡ Average Power Consumption Shenzhen Factory 6



920Hz 160000 LED Dots Indoor LED Video Screen 300W/㎡ Average Power Consumption Shenzhen Factory 7


2 LED Display piexl 1536 * 832
2 Module quantity 12pcs*13pcs =156 pcs
3 Brightness ≥1000 mcd/㎡
4 Brightness(Max./Min.) 1.2:1
5 Driving Method 1/32 Scan
6 View Angle Horizontal 140° Vertical 120°
7 Optimal Viewing Distance 3M
8 Brightness Control Red,Green and Blue 256 Grade/Each
9 Refresh rate >1920HZ
10 Frame Frequency 60Hz
11 Input Voltage AC220V/50Hz or AC110V/60Hz
12 Defects Rate ≤0.00001
13 Power Consumption Max.: 800W/㎡
Average: 300W/㎡
14 Screen weight ≤20kg/㎡
15 MTBF >10,000 hours
16 Life span ≥100,000 hours
17 Module Display Brightness Uniformity <2%
18 Earth Leakage Current <3mA
19 Protective Grade IP33
20 Temperature-operating ﹣25℃~45℃
21 Humidity-operating 10%~95%
22 Controlling system LINSN
23 Operating System WIN7/WIN8/WIN10
Remarks:
1. Software and User’s manual in English included.
2. 30% Down Payment before Production, Balance before shippment
3. Lead time:15 working Days against down Payment
4. Two Years Maintain Replacement free.
